Satellite
Language
- Select the desired text language for the device
-
Changing the text language does not affect the language of user entered data or map data
-
Language files are simple
*.xml files that can be
edited as desired with your favorite text editor, like
Notepad++
Voice Language
- Select the desired voice for vocal prompts
-
American English - Jack
-
American English - Michelle
- American English - Samantha
- Australian English - Karen
- Australian English - Lee
- British English - Daniel
- British English - James
- British English - Kate
- British English - Serena
- {additional options}
Power Key
-
Configure additional Power Key functions as desired
-
The selected Single Tap function will not be
available when:
-
The status page is displayed (single tap closes status page)
-
The Screen is turned off (single tap turns screen on)
Single Tap
Double Tap
Advanced
Setup
External Power Off
- Select the desired behavior when external
power is removed while powered on
-
Prompted
-
Turn Off
-
Stay On
External Power On
- Select the desired behavior when external
power is connected while powered off
Interface
- Sets the format of the data interface
- Montana 700/700i/750i
-
Garmin Spanner (Creates a virtual serial port for use with most NMEA 0183 compliant programs)
-
NMEA Sentences
-
Status (GSA, GSV)
-
Wpts/Route (WPL, RTE)
-
GRMN Propritary
-
Autopilot Mode
-
Waypoint IDs
-
Precision of Minutes
-
MM.MM' (2 digits)
-
MM.MMM' (3 digits)
-
MM.MMMM' (4 digits)
-
Baud
- Garmin Serial (Garmin proprietary data transfer format)
- NMEA In/Out (Provides standard NMEA 0183 input and output)
- NMEA Sentences
- Status (GSA, GSV)
- Wpts/Route (WPL, RTE)
- GRMN Propritary
- Autopilot Mode
- Waypoint IDs
- Precision of Minutes
- MM.MM' (2 digits)
- MM.MMM' (3 digits)
- MM.MMMM' (4 digits)
- Text Out (Provides simple ASCII text output of location and velocity information)
- MTP (Media Transfer Protocol)
- Montana 710/710i/760i
- Garmin (Prompts user to enter MTP Mode:
Selecting 'No' allows continued use of the device while connected)
- MTP (Media Transfer Protocol)
RINEX Logging
- Enable/Disable RINEX Logging
- Logs are saved in
[GPSr]\Garmin\RINEX\
Battery Type
- Displayed only when the
Garmin AA battery pack
is installed
- This setting calibrates the 'Battery
Status' indicators and has no affect on battery life
- Select the installed battery type
-
Alkaline
- Lithium
-
NiMH
-
Precharged
NiMH
