Rino 520
010-00392-00
Rino 530
010-00392-21
Rino 520HCx
010-00564-00
Rino 530HCx
010-00564-01
|
Rino 520 010-00392-00 |
Rino 530 010-00392-21 |
Rino 520HCx 010-00564-00 |
Rino 530HCx 010-00564-01 |
|
| General | ||||
| Unit Dimensions | 2.3” x 7.5” x 1.8” (5.8 x 19.0 x 4.6 cm) | |||
| Weight | 10.3 oz (292 g) with battery pack | |||
| Display Size | 1.3" x 1.7" (3.3 x 4.3 cm) | |||
| Display Resolution | 176 x 220 pixels | |||
| Display Type | 2.14" (5.4 cm) 256 level color TFT | |||
| Touchscreen | No | |||
| Waterproofing | IPX7 | |||
| Floats | No | |||
| Battery | Removable, Rechargeable 2400 mAh Li-ion battery pack or AA battery pack | |||
| Battery Life | 16 hours | 14 hours | 16 hours | 14 hours |
| Integral Battery Charger | No | |||
| GPS Antenna | Quad Helix | |||
| GPS Chipset | ||||
| High Sensitivity GPS Receiver | No | Yes | ||
| GNSS Networks | GPS + WAAS/EGNOS | |||
| Interface | mini USB | |||
| Operating Temperature | -4° to 140°F (-20° to 60°C) | |||
| Charging Temperature | 32° to 113°F (0° to 45°C) | |||
| Maps and Memory | ||||
| Basemap | Yes | |||
| Preloaded Map | No | |||
| Ability to Add Maps | Yes | |||
| Garmin Custom Maps | No | |||
| Garmin BirdsEye Maps | No | |||
| Internal Memory | 56 MB | No | ||
| Accepts Data Card | No | Yes (microSD, Max 4GB, Class 4 to 10) | ||
| Custom POIs | No | Yes | ||
| Waypoints | 500 | |||
| Routes | 50 | |||
| Track Log | 10,000 points, 20 saved tracks | |||
| Automatic Routing | Yes (with optional mapping for detailed roads) | |||
| Sensors | ||||
| Electric Compass | No | Yes | No | Yes |
| Barometric Altimeter | ||||
| UV Sensor | No | |||
| Microphone | Yes | |||
| Outdoor Recreational Features | ||||
| Geocaching Friendly | No | Yes | ||
| Outdoor GPS Games | Yes | |||
| Flashlight | No | |||
| Camera | ||||
| Picture Viewer | ||||
| Photo Navigation | ||||
| Hunt/Fish Calendar | Yes | |||
| Sun/Moon Information | ||||
| Area Calculation | ||||
| Tide Tables | Yes (with optional Bluechart) | |||
| FM Radio | No | |||
| Multimedia | ||||
| Wireless | ||||
| Garmin Connect | No | |||
| Smart Notifications | ||||
| LiveTrack | ||||
| Wireless Unit to Unit Transfer | ||||
| Connect IQ | ||||
| Active Weather | ||||
| VIRB Remote | ||||
| XERO Locations | ||||
| Bluetooth Headset | ||||
| Two-way Radio Features | ||||
| Frequency Band | FRS + GMRS | |||
| Channels | 22 | |||
| Squelch Codes | 38 (CTCSS) | |||
| Range | 2 miles (FRS), 14 miles (GMRS) | |||
| VOX (Voice Activation) | Yes | |||
| Location Reporting | ||||
| Contacts | No | |||
| Transmit Power | 0.5 watt (FRS), 2.0 watts (GMRS) Canada, 5.0 watts (GMRS) US | |||
| Vibration Alert | Yes | Yes | Yes | Yes |
| NOAA Weather Radio | No | No | ||
